Description
The 18V Brushless Hammer Driver Drill (DHP486) provides 141Nm of maximum fastening torque and no load speed of 2,100rpm combining rapid drilling speeds with high levels of torque. This model has been redesigned with a newly designed motor and gear ratio achieving not only more power but also increasing the performance in continuous heavy-duty applications. Not only has the performance on this model been increased but it is also considerably shorter. At 178mm in length this model is 27mm shorter than the previous model. Making it the most compact drill in its class and extremely comfortable to use in all applications.
Features
- Massive drilling capacity with 152mm hole saw & 50mm auger bit capacity
- Compact overall length only 178mm for use in narrow workspaces
- High powered brushless motor produces 141Nm peak torque
- High durability aluminum gear housing
- Mechanical 2 speed gearing with all metal gear construction
- Max Drilling Capacities in Wood:
- Auger Bit: 50mm
- Self-feeding Bit: 76mm
- Hole Saw: 152mm
- Max Drilling Capacities in Steel: 13mm
- Max Drilling Capacities in Masonry: 16mm
- No Load Speed:
- Hi: 0 - 2100rpm
- Lo: 0 - 550rpm
- Impact Rate:
- Hi: 0 - 31500ipm
- Lo: 0 - 8250ipm
- Max Peak Torque: 141Nm
- Max Tightening Torque:
- Hard: 130Nm
- Soft: 65Nm
- Overall Length: 178mm
- Voltage: 18V
- Dimensions: 320mm x 130mm x 205mm
- Skin Weight: 2.1kg
- Weight (With Battery): 2.7kg
- Aluminium hammer case
- One-touch bit installation, no need to pull bit sleeve for bit installation
- Twin LED job light with pre-glow and afterglow functions
- High rotation speed at 3600rpm
- Variable speed controlled by trigger
- Ergonomically designed handle with soft grip provides comfortable grip and more control while minimising hand fatigue and pain
- Electronic 3-stage impact power selection - in order to reduce fault tightening, hard/medium/soft impact power can be selected to the material of workpiece or screw type simply by pushing a button
- T-Mode is a special mode optimum for fast tightening of self drilling screws without damaging the screw and workpiece
- Voltage: 18V
- Capacity:
- Machine screw: M4 - M8
- Standard bolt: M5 - M16
- High strength bolt: M5 - M14
- Coarse thread (length): 22mm - 125mm
- Impacts per minute:
- Speed 1: 0 - 3800ipm
- Speed 2: 0 - 2600ipm
- Speed 3: 0 - 1100ipm
- No load speed:
- Speed 1: 0 - 3600rpm
- Speed 2: 0 - 2100rpm
- Speed 3: 0 - 1100rpm
- Max fastening torque: 175Nm
- Vibration level: 12.5m/s ²
- Sound pressure level: 96dB(A)
- Sound power level: 107dB(A)
- Dimensions (L x W x H): 117mm x 79mm x 236mm
- Weight: 1.2kg
- 3 Years Warranty Covered By Makita Australia
- Integrated L.E.D. battery charge level indicator allows user to monitor battery charge
- Up to 66% more run time per charge compared to BL1830
- Fast 45 minute charging time
- Battery delivers consistent power and run time in extreme temperatures, even in winter (-20 °C)
- Impact-resistant outer case and shock-absorbing inner-liner are engineered to protect the battery
- Sixteen contact terminals maintain a constant connection with the tool to help prevent power loss or fluctuation, even during high-vibration applications
- Battery resists self-discharge and remains ready for use even after long periods of storage
- Sensitive electronics are protected with a thick gel coating, preventing damage against dust and moisture
- Star protection computer controls - includes overload protection, over-discharge protection and over heat protection
- The battery and tool communicate, protecting your tool and battery from overload by cutting power when put under abnormally high current draw
- If the battery reaches a certain level of heat it will cut power to the tool, protecting the tool and battery from overheating
- Voltage: 18V
- Amp hour: 5.0Ah
- Cell type: Lithium-Ion
- Charging time: 45 minutes
- Weight: 0.6kg
- 2 Years Warranty covered by Makita Australia
- Built-in CPU - gathers information from the battery's memory chip to determine optimum charging method
- Forced air cooling fan - cools the battery to minimise charging time
- Digital power display identifies the condition of the battery and charging condition
- Voltage: 18V
- Cell capacity: 1.5Ah - 6.0Ah
- Charge Time:
- 1.5Ah: 15mins
- 3.0Ah: 22mins
- 4.0Ah: 36mins
- 5.0Ah: 45mins
- 6.0Ah: 55mins
- Length: 185mm
- Weight: 0.82kg
- 2 Years Warranty Covered By Makita Australia
Makita 18V Brushless Compact Twin Case
Important note: This twin case will only suit DHP480 / DHP481 and the DTD series Features:- Heavy Duty polyethylene constructed carrying case
- Can fit 2 x Tool, 2 x Batteries, 1 x Charger
