Description
Holes in series.
Festool's LR 32 adjustable shelving system allows quick and precise hole placement without time consuming measuring and marking.
Compatible with OF 1010 and OF 1400 routers, as well as previous OF 900 and 1000 models, the LR 32 easily creates 32 mm spaced shelf pin holes for your furniture.
The straight forward system (LR 32 SYS) contains clamps, stops, cutters and the guide plate that is fitted to the router. 8 mm cutter and 8 mm collet is required for the LR32 to work with the OF 1010.
The LR 32 guide rail with positioning holes is purchased separately in 1400 or 2424mm lengths. The rail can also be used as a regular guide rail with Festool routers, saws and jigsaws.
Main Applications
- for use with hole line guide rails
Specifications
- Hole Spacing: 32mm
- Length of series of holes (without guide extension): 1400 / 2424
- Side stop setting range: 0 - 110mm
Includes
- Guide Plate with Centering Mandrel
- 2 x Parallel Side Fences with Adjustable Stop
- 2 x Longitudinal Stops
- Hinge Location Cutter HW D 35mm
- Dowell Drill HW D 5mm
- Dowell Drill HW D 5 mm with cantering bit
- Adjustable Clamps 120mm - Pack 2
- 2 x Longitudinal Stops
- Systainer3 SYS 1 Medium 112mm x 396mm Storage Box
