GEARWRENCH 3/4" Drive Micrometer Torque Wrench 85065M

The GEARWRENCH family of torque wrenches & torque products offer the latest innovations in torque measurement. Included in the line are micrometer, tire shop, beam and electronic torque wrenches, as well as, torque multipliers. The micrometer wrenches are available in fixed head and flex head. The fixed head line offers wrenches in 1/4" to 3/4" drives. The flex head wrenches are available in 3/8" and 1/2" drives. The tire shop wrenches feature a rugged tire tread rubber cover on the head intended to specifically be used for checking wheel lug nuts and are available in 3/8" and 1/2" drives. The electronic torque wrenches ensure a more precise fastener torque level and are available in a 3/8" and 1/2" drives. The GEARWRENCH line of torque products allow the user to complete any job where accurate torque is required.

Features

• 36-tooth ratchet mechanism with a 10° swing arc allows you to turn fasteners in spaces other tools can't fit
• Torque accuracy of +/- 3% CW between 20% and 100% of wrench capability
• Twist locking collar provides a secure locking mechanism for consistent performance
• Scale markings are highly visible and easy to read
• Pliable, elastomer handle lets you grip comfortably, while oil and solvent resistance feature keeps your hands in place
• Meets or exceeds ISO 6789 and ASME B107.300-2010 standards and specifications
• 1 year limited warranty; calibration accuracy warrantied for 90 days


Specifications

• Prop 65 : WARNING: This product contains or produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.

• ASME Specification : B107.300

• Tether Ready : No

• Minimum Torque (Primary Scale) : 100 ft/lb

• Maximum Torque (Primary Scale) : 600 ft/lb

• Minimum Torque (Alt Scale) : 152.6 Nm

• Maximum Torque (Alt Scale) : 830.6 Nm

• Torque Accuracy (20-100% of Full Range) : +/-3% Clockwise

• Certified : No

• Head Thickness Less Tang : 0.37 in

• Primary Scale Increments : 2.5 ft/lb

• Alt Scale Increments : 3.4 Nm

• Head Thickness : 1.14 in

• Type : Micrometer

• Knurled : Yes

• Flexible : No

• Overall Length : 42.4 in

• Head Width : 2.62 in

• Packaging : Boxed

• Weight (Catalog) : 15.8 lb

• Warranty : 90 Days Calibration/1 Year on Parts

• Drive Tang Size : 3/4 in

• Head Length : 1.97 in

• Tooth Count : 36

• Finish : Full Polish Chrome

• Overall Height : 2.6 in

• UPC : 099575005657

• Included Storage : Blow Mold Case

• Overall Width : 2.6 in

• Material : Alloy Steel


Includes

• Calibration Certificate
