Description
The Imex LX22G crossline laser level features ultra-bright green beam technology with one horizontal and one vertical line, plumb up and plumb down. Series II features an all-new sturdy magnetic bracket enabling quick release of the laser without screws to hold it in place. The new 5.2Ah lithium battery pack gives you plenty of run time to keep up with your busy day on site, featuring USB-C fast charge. Locally calibrated and tough to withstand the knocks and bumps on site, the LX22G Series II has rubberised housing for a comfortable, non-slip grip.
Features
- NEW quick release magnetic bracket – no screws to hold laser in place
- NEW 5.2Ah lithium battery pack – swaps to all LX series II models. OPTION for LX22 – comes with AA battery pack as standard
- NEW rugged housing with non-slip rubberised moulding
- High visibility green beam technology
- Plumb up, plumb down
- 1 horizontal, 1 vertical line
- Pulse mode for detector
- Self levelling
In keeping with Imex’s legendary laser and measuring equipment offer, the LX22G crossline laser level comes with a full 3 year warranty and a world first in this price point, a full Calibration Certificate, verifying its accuracy and serviceability.
| Imex LX22G Green Beam | Specifications |
|---|---|
| Self levelling range | 4° ± 1 |
| Out of level indication | laser blinks on/off |
| Laser lines / dots | 1 vertical, 1 horizontal line, plumb up/down dots |
| Laser accuracy | ±3mm @10m |
| Laser class | Class 2 |
| Laser wavelength | 635 ± 10 nm |
| Laser distance | 10m light-dependent |
| Laser distance with optional detector | 50m |
| Power source | 5.2 Ah lithium ion |
| Charging type | USB-C |
| Run time- both beams | 10 hrs |
| Control switch | 1 button, pendulum lock |
| IP Rating | IP54 |
| Operating temperature | -10° to +50°C |
| Storage temperature | -20° to +70° C |
| Kit Inclusions | lithium battery,alkaline batteries, magnetic bracket operating manual, plastic carry case |
Used for Cabinet Installation, Wall and floor tiling, Wall Partitions, Window and door placement, Interior decorating, Ceilings & Dry Walling, Electrical switch and light placement, Balastrading, Fencing, Foundations, Brick work set out, Concrete work, Plumbing Set-out, Steel fabrication alignment and set out.
