12V 2.5Ah CXS Mini Cordless Drill Set 576870 by Festool

Light, compact and impressively strong. The CXS 12 compact screwdriver is your ideal helper for the most varied everyday work. The ergonomic C shape facilitates precise working through the grip position in the drilling and screwdriving axis. A number of attachments find solutions for the most difficult applications – perfect also for narrow spaces or corners. The FastFix interface and the CENTROTEC system ensure fast tool changes. The compact battery pack is compatible with all chargers in the 18-volt cordless range. Clever details like the bit holder, the light control and the Systainer³ make the CXS 12 a compact, multitalented device with practical special equipment

• Impressive ergonomics and low weight for easy drilling and fastening.
• The compact, handy shape makes work easier, even in cramped spaces.
• Impressive performance: Thanks to the extremely powerful, brushless and therefore long-lasting EC-TEC motor.
• The ergonomic C-shape of the direct handle in the screwing axis enables more targeted power transmission and more precise work
• Quick conversion to drilling, screwdriving, angular drilling and angular screwdriving without the need for tools thanks to the FastFix interface.
• Numerous attachments for a variety of applications. All attachments for the current 18 V screwdrivers are compatible with CXS 12
• The depth stops and eccentric adapter enable depth-limited screwdriving close to edges.
• High-quality lithium-ion battery with workpiece-friendly rubber coating, charge indicator and 2.5 Ah for a long service life included in the scope of delivery. Compatible with all chargers in the Festool 18-volt cordless range
• Including exchangeable CENTROTEC tool chuck and 10 mm FastFix keyless chuck
• Integrated magnetic bit holder.
• The work area is optimally lit by LED lighting that can be switched on.
• Simply mobile. The CXS 12 comes in a practical lid compartment Systainer³ for quick access to drilling and screwdriving accessories
• 13 torque settings and torque switch-off for precision fastening.
• Robust belt clip that can be mounted on both sides.

Main applications

• Furniture, fittings and kitchen assembly
• Installation of skirting boards, boxes, lamps, curtain rods
• Interior finishing
• Installation of skylights
• Manufacture of façade panelling and patio decks
• Light and medium drilling and screwdriving in wood, metal and plastic
• Screwdriving into wood up to 6x200 mm (reference value for countersunk screws with partial thread in softwood. The maximum screw size that can be used varies depending on the screw type and wood type)
• Drilling in wood up to dia. 35 mm with Forstner drill bits

Short design

With a length of 15.6 cm and a height of 17.7 cm, the CXS 12 is extremely compact and ergonomic. With the handle positioned on the drilling and screwing axis directly behind the motor, the handy and perfectly balanced C-design enables extremely precise work.

Compact 12 V battery pack

With workpiece-friendly rubber coating and charge indicator. Compactness combined with compatibility with all chargers in the Festool 18-volt cordless range.

Bits always at hand

The practical integrated bit holder provides space for multiple bits – magnetically secured against falling out.

Impressive performance

The CXS 12 also performs impressively when working with Forstner drill bits up to 35 mm and screwdriving up to 6x200 mm in softwood (reference value for countersunk screws with partial thread in softwood. The maximum screw size that can be used varies depending on the screw type and wood type).

Optimal lighting

With the integrated LED light, you can work precisely even in dark corners – continuous lighting, afterglow or LED off can be controlled via the adjusting wheel.

Everything is close to hand in an instant

Always at your fingertips, keep your hands free at the right moment: The belt clip can be positioned for right and left handed individuals.

CENTROTEC tool chuck

For instantly changing between drilling, countersinking and screwdriving: The CENTROTEC tool chuck, which has proven itself since 2001, is a chuck and bit holder in one. For use with numerous CENTROTEC accessories.

Unique system width and perfect system compatibility

Owing to the smart FastFix interface, all attachments of the current 18 V screwdriver are compatible with the CXS 12. One compact screwdriver – so many different applications.

In the smallest of spaces

The angle attachment is perfect for work around corners and reaching concealed screws at tight angles. Bits can also be inserted into the direct holder of the spindle in narrow spaces.

Chuck for standard tools

The chuck with a clamping range of up to 10 mm is always included in the scope of delivery – for all tools with a cylindrical shaft. Tool-free mounting via the FastFix interface.

Precise work

With the handle positioned on the drilling and screwing axis directly behind the motor, the handy and perfectly balanced C-design enables extremely precise work.

• Battery voltage : 10.8V
• Battery Capacity (Ah): 2.50 Ah
• No Load Speed 1st Gear (rpm): 0 - 470
• No Load Speed 2nd Gear (rpm):  1600 min⁻¹
• Drilling Diameter Wood (mm): 35 mm
• Gears: 2
• Torque Adjustment 1st Gear (Nm): 1.1 - 8 Nm
• Torque Adjustment 2nd Gear (Nm): 0.4 - 2.3 Nm
• Maximum Torque Wood (Nm): 17 Nm
• Maximum Torque Steel (Nm): 30 Nm
• Chuck Range (mm): 1 - 10 mm
