Description
A favourite of woodworkers and hobbyists that do not require large cutting capacity and power for their projects, or have limited shop space for a larger size bandsaw. Includes features for easy operation – tilting 0-45° table, rip fence, large blade tension knob, dust port for shop vacuum hookup, and on/off switch. The reduced size is ideal for transporting, or storing, when not in use.
Features
- Rugged steel frames
- Balanced cast aluminium drive wheels
- Machined cast iron tables with mitre gauge slots
- Easy Access blade tension systems
- Rack and Pinion upper guide adjustments
- Dust collection ports
Note: The Switch pictured is US version (AU version is slightly different).
Additional Information
Model
Type
Bandsaw
SKU
9700024
Part Number
10-305
Brand
Rikon
Technical - Main
Power Source
Power Source
Any source of power which provides the energy required to drive a piece of machinery or equipment and includes, but is not limited to: electrical, steam, hydraulic, water, air, mechanical, radiation, and thermal forms of energy.
230-240V 50Hz (Single Phase)
Motor Power (Input)
Motor Power (Input)
Input power means the full-load power input required to operate the motor.
250W
Motor Power (Output)
Motor Power (Output)
Output power means the maximum power that the motor puts out under ideal conditions.
200W
Blade Length
1790mm
Blade Width
6-13mm
Throat Capacity
245mm
Table Size
350 x 318mm
Table Height
920mm (using optional stand)
Dimensions
Product Length
670mm
Product Width
470mm
Product Height
1470mm
Product Weight (Net Weight)
36kg
Country of Origin
Designed, Researched & Developed in
USA
Manufactured in
China
Features
Rack & Pinion
Rack & Pinion
A rack and pinion is a type of linear actuator that comprises a circular gear (the pinion) engaging a linear gear (the rack).
Tool Less Blade Guide System
Tool Less Blade Guide System
Tool Less Blade Guide System features quick adjusting, spring loaded, ball bearing blade guides for fast and easy setting to the blades.
Blade Tensioning Quick Release Device
Blade Tensioning Quick Release Device
Lever to ensure quick release of blade tensioning when not in use to help prevent blade stretching and deforming the band saw tyres, which are likely made of rubber or urethane. A stretched blade will cause the operator to increase blade tension to compensate, increasing blade break risk. De-tensioning your blade will extend the life of your blade.
Mitre Gauge Included
Drift Bar
Drift Bar
The drift bar acts as a thickness gauge and adjusts the angle of cut with the scribed line, ensuring a uniform thickness without putting undue strain on the blade.
Tilting Table
Tilting Table
A tilting table in a machine is a mechanical component designed to adjust the angle or orientation of a work surface or workpiece relative to the machine's axis of operation. This adjustable feature enables operators to position the workpiece at different angles, facilitating various machining processes such as drilling, milling, or grinding. Tilting tables are commonly found in machining centers, allowing for greater flexibility in manufacturing operations by accommodating different machining requirements and achieving precise workpiece positioning for optimal results.
Standard Inclusions
Mitre GaugeRip FenceBandsaw Blade
Workshop (Site) Info
Electrical Connection
10Amp Lead & Plug
Dust Hose Inlet Diameter
1 x 63.5mm (2-1/2") OA, 58mm (2-1/4") ID
Footprint
235mm x 400mm (Machine Footprint Base)
Workshop Requirements
Benchtop or Stand
Spare Parts / Consumables
Spare Parts / Consumables
- 1790mm x 10mm x 10TPI Bi-Metal Bandsaw Blade suit Wood Cutting
- 1790mm x 10mm x 10TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 10mm x 24TPI HSS Bandsaw Blade suit Wood Cutting - Manufactured Locally *Custom Made To Order*
- 1790mm x 10mm x 4TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 10mm x 6TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 12.5mm x 3TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 12.5mm x 6TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 3mm x 14TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 6mm x 10TPI HSS Bandsaw Blade suit Wood Cutting
- 1790mm x 6mm x 6TPI HSS Bandsaw Blade suit Wood Cutting
- Woodfast Universal Sacrificial Plastic Bandsaw Table Inserts 60mm (4Pce) suit Bandsaws
- Plastic Table Inserts suit Bandsaws C10-393
- Quick Adjust 150mm (6") Tall Rip Fence System 10-920 suit Bandsaws by Rikon
- Mitre Gauge 13-920 by Rikon
- Zero Clearance Table Inserts 60mm (4Pce) suit BS250B, BS230A,10-305, 10-306, 10-3061 or similar Bandsaws by Woodfast
Warranty
Warranty
Warranty
All of our products come with full manufacturer's warranty. If you need to make a claim - all you need is the tax invoice from your purchase. If you lose your original tax invoice and need to make a claim, please let us know and we'll re-issue it to you.
5 Years
Packaging + Shipping
Shipping Length
850mm
Shipping Width
320mm
Shipping Height
420mm
Shipping Weight (Gross)
36kg
Packaging
Packaging
Items over 25kg must be packed on a pallet or crate so they can easily be moved by forklift.
Cardboard Box
Packaging Box Qty
1
Forklift / Tail Lift to Unload is Highly Recommended
Shipping Notes
Shipping Notes
It is highly recommended that goods over 25Kg are handled with a forklift / tail lift. For items over 32kgs, you must ensure there is assistance for loading and unloading unless you have selected the Tail lift options, otherwise there will be additional fees.This is for safe handling for the product and the handler.Please ADD a Tail Lift to your order - should you wish to include a Tail Lift.Goods over 50Kg must be handled by a Forklift / Tail Lift.
This product is classified as 'Heavy / Oversized' and generally does not qualify for FREE SHIPPING.
Product Specification Disclaimer
Product Specification Disclaimer
Product Specification Disclaimer
The specifications provided on our product pages are obtained from various manufacturers and third-party sources. While we strive to ensure that the information is accurate, we do not warrant or guarantee its accuracy, completeness, or timeliness. Therefore, we cannot be held liable for any errors, omissions, or discrepancies in the specifications provided.Please note that product specifications are subject to change by the manufacturers without notice. It is recommended to verify the specifications with the manufacturer or seller before making a purchase decision.In the event of any discrepancy between the product specifications on our website and the actual product, the latter shall prevail.We reserve the right to update, modify, or remove product specifications at any time without prior notice.
Product Accessories
Brochure
Brochure
What's Included
250mm (10″) Benchtop Bandsaw 0.33HP 240V 10-305 by Rikon
