300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
Roll over image to zoom in Click on image to zoom
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar

300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar

SicarSKU: 8601392
Price:
$9,500.00

Tax included Shipping calculated at checkout

Stock:
Re-stocking soon

Pickup available at 23 Exhibition Drive

Usually ready in 24 hours

CLICK HERE to Shop our Sale!

Downloads

Description

Specifications

  • Main Blade Diameter φ300 x φ30mm
  • Main Blade Speed 4000 RPM
  • Scoring Blade Diameter φ120 x φ22mm
  • Scoring Blade Speed 8000mm
  • Mαx Depth of Cut @ 45 ° 92mm
  • Max Depth of Cut @ 90 ° 120mm
  • Max Rip Capacity 1250mm
  • Main Table Size 910x550mm
  • Main extend Table Size 910x760mm
  • Side extend Table Size 500x550mm
  • Dust Extraction Outlet φ120mm
  • Overhead blade guard with 100mm dust port
  • Main Blade Motor Output 5.5HP
  • Scoring Blade Motor Output 0.75KW 1HP
  • Net/Gross Weight 610/710KG
  • Mαin Package 2220×1030×1150mm
  • Sliding Beam Size(W.x L.) 3560×420×210mm
  • CE Style Overhead Guard Included

Additional Information

Model
Type
Panel Saw
SKU
8601392
Part Number
SEGA300/415V/1.6M
Brand
Sicar
Technical - Main
Power Source
Power Source
Any source of power which provides the energy required to drive a piece of machinery or equipment and includes, but is not limited to: electrical, steam, hydraulic, water, air, mechanical, radiation, and thermal forms of energy.
415V 50Hz Three Phase
Motor Power (Output)
Motor Power (Output)
Output power means the maximum power that the motor puts out under ideal conditions.
5HP (3.73kW)
Blade - Electric Rise / Fall
No
Cut Max. Depth @ 45°
92mm
Cut Max. Depth @ 90°
120mm
Rip Capacity
1250mm
Technical - Saw
Sliding Table (Cross Cut) Size
1600mm
Blade (Main) - Bore Size (mm)
30mm
Blade (Main) - Diameter (Max.)
300mm
Blade (Main) - Speed
4000RPM
Blade (Scoring) - Diameter (Max.)
120mm
Blade (Scoring) - Speed
8000RPM
Blade Tilt
0-45°
Workshop (Site) Info
Electrical Connection
Excludes Plug & Lead (must be connected by Licensed Electrician)
Packaging + Shipping
Shipping Weight (Gross)
1.48kg
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
$9,500.00
