300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar
Roll over image to zoom in Click on image to zoom
300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar

300mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA300 by Sicar

SicarSKU: 8601392
Price:
$9,500.00

Tax included Shipping calculated at checkout

Stock:
Re-stocking soon

Pickup available at 23 Exhibition Drive

Usually ready in 24 hours

CLICK HERE to Shop our Sale!

Downloads

Description

Specifications

  • Main Blade Diameter φ300 x φ30mm
  • Main Blade Speed 4000 RPM
  • Scoring Blade Diameter φ120 x φ22mm
  • Scoring Blade Speed 8000mm
  • Mαx Depth of Cut @ 45 ° 92mm
  • Max Depth of Cut @ 90 ° 120mm
  • Max Rip Capacity 1250mm
  • Main Table Size 910x550mm
  • Main extend Table Size 910x760mm
  • Side extend Table Size 500x550mm
  • Dust Extraction Outlet φ120mm
  • Overhead blade guard with 100mm dust port
  • Main Blade Motor Output 5.5HP
  • Scoring Blade Motor Output 0.75KW 1HP
  • Net/Gross Weight 610/710KG
  • Mαin Package 2220×1030×1150mm
  • Sliding Beam Size(W.x L.) 3560×420×210mm
  • CE Style Overhead Guard Included

Additional Information

Model
Type
Panel Saw
SKU
8601392
Part Number
SEGA300/415V/1.6M
Brand
Sicar
Technical - Main
Power Source
Power Source
Any source of power which provides the energy required to drive a piece of machinery or equipment and includes, but is not limited to: electrical, steam, hydraulic, water, air, mechanical, radiation, and thermal forms of energy.
415V 50Hz Three Phase
Motor Power (Output)
Motor Power (Output)
Output power means the maximum power that the motor puts out under ideal conditions.
5HP (3.73kW)
Blade - Electric Rise / Fall
No
Cut Max. Depth @ 45°
92mm
Cut Max. Depth @ 90°
120mm
Rip Capacity
1250mm
Technical - Saw
Sliding Table (Cross Cut) Size
1600mm
Blade (Main) - Bore Size (mm)
30mm
Blade (Main) - Diameter (Max.)
300mm
Blade (Main) - Speed
4000RPM
Blade (Scoring) - Diameter (Max.)
120mm
Blade (Scoring) - Speed
8000RPM
Blade Tilt
0-45°
Dimensions
Product Weight (Net Weight)
610kg
Workshop (Site) Info
Electrical Connection
Excludes Plug & Lead (must be connected by Licensed Electrician)
Dust Hose Inlet Diameter
1 x 120mm
Packaging + Shipping
Shipping Weight (Gross)
1.48kg
Shipping Notes
Shipping Notes
It is highly recommended that goods over 25Kg are handled with a forklift / tail lift. For items over 32kgs, you must ensure there is assistance for loading and unloading unless you have selected the Tail lift options, otherwise there will be additional fees.This is for safe handling for the product and the handler.Please ADD a Tail Lift to your order - should you wish to include a Tail Lift.Goods over 50Kg must be handled by a Forklift / Tail Lift.
This product exceeds hand unloading limits and requires a tail lift truck or forklift at the unloading location (Receivers end).
Product Specification Disclaimer
Product Specification Disclaimer
Product Specification Disclaimer
The specifications provided on our product pages are obtained from various manufacturers and third-party sources. While we strive to ensure that the information is accurate, we do not warrant or guarantee its accuracy, completeness, or timeliness. Therefore, we cannot be held liable for any errors, omissions, or discrepancies in the specifications provided.Please note that product specifications are subject to change by the manufacturers without notice. It is recommended to verify the specifications with the manufacturer or seller before making a purchase decision.In the event of any discrepancy between the product specifications on our website and the actual product, the latter shall prevail.We reserve the right to update, modify, or remove product specifications at any time without prior notice.
