5 in 1 Combination Machine C400 by Sicar

Save $1,100.00
SicarSKU: 8601390

Price:
Sale price$17,899.00 Regular price$18,999.00

Tax included Shipping calculated at checkout

Stock:
In stock (2 units), ready to be shipped

Pickup available at 23 Exhibition Drive

Usually ready in 24 hours

CLICK HERE to Shop our Sale!

Description

The C400 Combined Machine has been specifically designed be an industrial standard machine, but at a size intended for the factory and small professional workshop. This industrially rated machine features a table saw and sliding table, planer, thicknesser and spindle moulder unit. The cast iron construction, accurate cross cut fence and superb build quality put this machine in a class of its own. Being a professional standard machine, the C400 of course is fully adjustable and the accuracy is second to none. As far as accuracy goes it will not even be bettered by full sized industrial machines. With three independent class 1 motors providing ample power, changing function can be done with the flick of a switch rather than the going through the laborious task of changing belts. The saw utilises a sliding beam which runs along side the blade like a panel saw. By running the beam this close to the blade, 100% accuracy is assured. The planer thicknessing function, again is of the highest quality, extremely powerful, accurate and the end result is simply sublime. The inward swing of the thicknessing unit keeps this machine compact in every function,whilst the cast iron construction means even heavy pieces can be handled confidently. Several further options are also available, each machine can therefore be tailored to the users specific needs. These options include; heavy duty morticing unit, spindle moulder ring fence, power feeder and tenoning hood.

Features

  • 5 in 1:
    • Table Saw
    • Spindle Moulder
    • Planer
    • Thicknesser
    • Mortiser
  • Three motors
  • Tilting functionality on Saw Blade
    • Scoring Saw
Specifications (Generally):
  • Three-phase motor 5.3HP / 4kw
  • Voltage 415V
  • Carriage dimensions 2600x315mm
  • Weight: 645kg
  • Packing Weight N .W/G.W 645/ 690kg
Planer with Spiral Head Cutter Block:
  • Spiral Cutter Block
  • Working table: 400 x 1800mm
  • Cutter block diameter: 70mm
  • Cutter block rotation speed: 5700RPM
  • Cutter block length: 400mm
  • Max table adjustment: 4mm
Thicknesser with Spiral Head Cutter Block:
  • Working table: 400 x 760mm
  • Feed speed: 7m/Min.
  • Working height: 4-220mm
  • Cutter block rotation speed: 5700RPM
  • Max cutting depth: 4mm
Table Saw / Circular Saw:
  • Working table: 326 x 1112mm
  • Main shaft speed: 4500 r.p.m
  • Scribe shaft speed: 7000 r.p.m.
  • Main blade diameter: 300 x 30mm
  • Scribe blade diameter: 90 x 22mm
  • Cutting height at 90 °: 100mm
  • Cutting width parallel fence: 730mm
Spindle Moulder:
  • Working tables: 326x1112mm
  • Shaft rotation speeds: 2000/3100/4400/7000RPM
  • Standard shaft diameter: 30mm
  • Shaft vertical stroke: 115mm
  • Max. tool diameter: 180mm
  • Max. tenoning depth: 65mm
Mortiser:
  • Working table: 250 x 500mm
  • Longitudinal stroke: 205mm
  • Traversal stroke: 95mm
  • Vertical stroke: 90mm
  • Chuck: 16mm
  • Chuck rotation speed: 5700RPM
Optional Accessories:
  • 100mm Dust Hose #8600640
  • FM300 Dust Collector
Optional Consumables:
  • Blades
  • Main blade = 250 x 30mm x 24T
  • Main blade = 250 x 30mm x 80T #8714666
  • Scribe Blade = 90 x 22mm
Full 12 Month Manufacturer Warranty
