Thermoforming Oven + Vacuum Press ROCO Standard by Ribex

Roll over image to zoom in Click on image to zoom

Thermoforming Oven + Vacuum Press ROCO Standard by Ribex

Name: Thermoforming Oven + Vacuum Press ROCO Standard by Ribex
Brand: Ribex
SKU: 8000796
Price: 72573.00 USD
Availability: InStock

RibexSKU: 8000796

Price:

$72,573.00

Stock:

Order In

Quantity:

Share this product

Thermoforming Oven + Vacuum Press ROCO Standard by Ribex, Manufactured in Turkey

Perfectly capable of making the entire thermoforming processes of all kinds of solid surface types and Thermoplastics respectively heating process to ensure flexibility of material then forming and cooling process by vacuum unit.

Heating Unit:-

Heating Power : 13.5 kW
Total Power : 15 kW
Heating chamber dimensions 2600 x 1250 mm.
Max. working temperature 230 ° C.
Uniform heat distribution inside heating chamber by
Patented RIBEX ROCO hot air circulation system
150 mm heat insulated walls
Heat resistant wire oven grill and optional portable stainless steel perforated plate 2000 x 1000 mm for thermoplastics

Vacuum Forming Unit:-

Table surface dimensions 2770 x 1300 mm
Multi hole durable metal table for balanced air suction
Rotary vane GERMAN Becker Vacuum Pump VT 4.40
Vacuum pressure max 9t/m² - displacement 40 m³/h
Silicone membrane natural rubber | Colour: Transparent White
Vacuum Sealed Membrane Frame

Control Unit:-

PLC and HMI Touch Screen controller (24 VDC)
Smart Temperature Controller
Easy to operate with multilangual menu
Digital on-screen vacuum gauge, heating time and vacuum time counters
Alarm Page, Input/Output Pages, Buzzer with light
Preset program menu for different workshops
Test, Manual or Automatic program running

Specifications:-

Overall Dimensions WxLxH	:	1700/3300/1100 mm
Gross Weight	:	1180 kgs
Heating Chamber Area WxLxH	:	1250mm/2600mm/110mm
Vacuum Table Area WxLxH	:	1300mm/2770mm/0-400mm
